EMINENCE DELTA 10A 10" , 8OHM SPEAKER

DELTA 10A

EMINENCE DELTA 10A, 10" , 8 OHM SPEAKER. RATED AT 350 WATTS PEAK. BEST TONE AND RELIABILITY. AS USED IN OUR 410 BASS CABINETS. EXCELENT GENERAL REPLACEMENT FOR  410 CABS.

SPECIFICATION
Nominal Basket Diameter  10", 254mm
Nominal Impedance*  8 ohms
Power Rating
Watts 350W
Music Program  700W
Resonance 66Hz
Usable Frequency Range  63Hz-3.7kHz
Sensitivity*** 98.8
Magnet Weight  56 oz.
Gap Height  0.375", 9.53mm
Voice Coil Diameter 2.5", 63.5mm

THIELE & SMALL PARAMETERS
Resonant Frequency (fs)  66Hz
DC Resistance (Re)  5.42
Coil Inductance (Le)  0.74mH
Mechanical Q (Qms)  6.53
Electromagnetic Q (Qes)  0.35
Total Q (Qts)  0.33
Compliance Equivalent Volume (Vas)  30.5 liters / 1.1 cu.ft.
Peak Diaphragm Displacement Volume (Vd)  121cc
Mechanical Compliance of Suspension (Cms)  0.18mm/N
BL Product (BL)  14.4 T-M
Diaphram Mass inc. Airload (Mms)  32 grams
Efficiency Bandwidth Product (EBP)  189
Maximum Linear Excursion (Xmax)  3.5mm
Surface Area of Cone (Sd)  344.9 cm2
Maximum Mechanical Limit (Xlim)  9.4mm

MOUNTING INFORMATION
Recommended Enclosure
Sealed N/A
Vented 12.7-37.9 liters/0.45-1.34 cu.ft.
Overall Diameter  10.09", 256.2mm
Baffle Hole Diameter  9.15", 232.4mm
Front Sealing Gasket  Fitted as standard
Rear Sealing Gasket  Fitted as standard
Mounting Holes Diameter  0.25", 6.4mm
Mounting Holes B.C. D.  9.66", 245.4mm
Depth 4.25", 108mm
Net Weight  10.8 lbs., 4.9 kg
Shipping Weight  12 lbs., 5.4 kg

MATERIALS OF CONSTRUCTION
Coil Construction  Aluminum voice coil
Coil Former Polyimide former
Magnet Composition  Ferrite magnet
Core Details  Vented core
Basket Materials  Pressed steel basket
Cone Composition  Paper Cone
Cone Edge Composition  Cloth cone edge
Dustcap Composition Solid composition paper dust cap

$ 135.00

Quantity :
